Key Features

• Reverse airflow (inverted design): The blades rotate counterclockwise, placing the fan’s airflow direction opposite to standard fans — useful for specific airflow strategies or use as an intake from a different orientation.
• ARGB lighting: Integrated side-ring ARGB lighting enables ambient effects customizable via your motherboard’s ARGB control.
• Optimal balance: Maintains a balance between airflow and noise thanks to its 1,500 RPM cap and S-FDB bearing design.
• Universal compatibility: Standard 120×25 mm form factor, compatible with most ATX and micro-ATX cases.

Performance & Use Cases

With a maximum airflow of 34.43 CFM and static pressure of 1.31 mm H₂O, this fan is capable of handling moderate airflow demands — suitable for general case intake, radiator assist, or reverse-flow scenarios. Its noise ceiling of 23.2 dBA ensures it remains unobtrusive even under load.

Design & Build Quality

The TL-M12RW-S is constructed from durable PBT+PC materials, offering rigidity and long-term stability. The frame includes integrated lighting channels while retaining structural integrity. Despite its reverse-blade configuration, it maintains structural design consistency and balance to minimize vibration.

Installation & Integration

It uses a 4-pin PWM connector for speed control (0.15 A) and a 3-pin 5V ARGB header for lighting. The cable lengths are sufficient for typical case layouts and motherboard placements. The fan is easy to mount with standard fan screws and fits in any 120 mm bay. Ensure your ARGB controller or motherboard supports 5V ARGB headers.

Why Choose TL-M12RW-S?

This fan is especially suited for users who want a reverse airflow option combined with aesthetic ARGB lighting. It’s a solid pick for builds that require airflow direction customization, or where symmetric fan layout is desired while maintaining lighting consistency. Plus, its quiet operation makes it favorable for daily use.
